Cold Rolled Stainless Steel Tube Pipe 201 304 321 2205 2507 904L
| Place of Origin | China |
|---|---|
| Brand Name | Hongyiyuan |
| Certification | ISO |
| Model Number | 321, 316, 316L, 316Ti, 316F, 316LTi, 309S, 310, 310S, 904L |
| Minimum Order Quantity | 1 Ton |
| Price | Negotiate |
| Packaging Details | Standard Seaworthy Package |
| Delivery Time | 7-15 work days after paid |
| Payment Terms | T/T |
| Supply Ability | 1000tons/months |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product | Stainless Steel Pipe | Standard | ASTM GB AISI JIS EN |
|---|---|---|---|
| Grade | 201 304 321 2205 2507 904L | Thickness | 0.5-50mm |
| Length | 2000mm, 2438mm, 3000mm, 6000mm Or As Required | Price Term | EXW,FOB,CIF,FCA |
| Processing Service | Punching, Cutting,Welding | Application | Construction,Decoration,Industry,machine Building,Exhaust Pipe |
| Delivery Time | 7-15 Days After Paid | MQO | 1 Ton |
| Payment Terms | 30%T/T,L/C | ||
| Highlight | Cold Rolled Stainless Steel Tube Pipe,Stainless Steel Tube Pipe 201,2205 304 stainless steel pipe |
||
Product Description
Product Description
Stainless steels are most notable for their corrosion resistance, which increases with increasing chromium content. Additions of molybdenum increase corrosion resistance in reducing acids and against pitting attack in chloride solutions. Thus, there are numerous grades of stainless steel with varying chromium and molybdenum contents to suit the environment the alloy must endure. Stainless steel's resistance to corrosion and staining, low maintenance, and familiar luster make it an ideal material for many applications where both the strength of steel and corrosion resistance are required.
Chemical Composition
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo |
| 201 | ≤0 .15 | ≤0 .75 | 5. 5-7. 5 | ≤0.06 | ≤ 0.03 | 3.5 -5.5 | 16 .0 -18.0 | - |
| 202 | ≤0 .15 | ≤l.0 | 7.5-10.0 | ≤0.06 | ≤ 0.03 | 4.0-6.0 | 17.0-19.0 | - |
| 301 | ≤0 .15 | ≤l.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 6.0-8.0 | 16.0-18.0 | - |
| 302 | ≤0 .15 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 8.0-10.0 | 17.0-19.0 | - |
| 304 | ≤0 .0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 8.0-10.5 | 18.0-20.0 | - |
| 304L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0-13.0 | 18.0-20.0 | - |
| 309S | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0-15.0 | 22.0-24.0 | - |
| 310S | ≤0.08 | ≤1.5 | ≤2.0 | ≤0.035 | ≤ 0.03 | 19.0-22.0 | 24.0-26.0 | |
| 316 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0- |
| 316L | ≤0 .03 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0 - 15.0 | 16 .0 -1 8.0 | 2.0 - |
| 321 | ≤ 0 .08 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0 - 13 .0 | 17.0 -1 9.0 | - |
| 630 | ≤ 0 .07 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.03 | 3.0-5.0 | 15.5-17.5 | - |
| 631 | ≤0.09 | ≤1.0 | ≤1.0 | ≤0.030 | ≤0.035 | 6.50-7.75 | 16.0-18.0 | - |
| 904L | ≤ 2 .0 | ≤0.045 | ≤1.0 | ≤0.035 | - | 23.0·28.0 | 19.0-23.0 | 4.0-5.0 |
| 2205 | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.030 | ≤0.02 | 4.5-6.5 | 22.0-23.0 | 3.0-3.5 |
| 2507 | ≤0.03 | ≤0.8 | ≤1.2 | ≤0.035 | ≤0.02 | 6.0-8.0 | 24.0-26.0 | 3.0-5.0 |
| 2520 | ≤0.08 | ≤1.5 | ≤2.0 | ≤0.045 | ≤ 0.03 | 0.19 -0. 22 | 0. 24 -0 . 26 | - |
| 410 | ≤0.15 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.03 | - | 11.5-13.5 | - |
| 430 | ≤0.1 2 | ≤0.75 | ≤1.0 | ≤ 0.040 | ≤ 0.03 | ≤0.60 | 16.0 -18.0 | - |
Surface Description
|
Surface |
Definition |
Application |
|
No.1 |
The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. |
Chemical tank, pipe etc. |
|
No.3 |
Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. |
Kitchen utensils, Building construction etc. |
|
No.4 |
Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. |
Kitchen utensils, Building construction, Medical equipment etc. |
|
2B |
Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. |
Medical equipment, Food industry, Construction material, Kitchen utensils etc. |
|
BA (No.6) |
Those processed with bright heat treatment after cold rolling. |
Kitchen utensils, Electric equipment, Building construction etc. |
|
Mirror (No.8) |
Shinning like a mirror |
Building construction, decoration etc. |
|
Hairline |
Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. |
Building Construction etc. |
Product Packing
Product Application
Stainless steels are most commonly used for their corrosion resistance. The second most common reason stainless steels are used is for their high temperature properties. Stainless steels can be found in applications where high temperature oxidation resistance is necessary, and in other applications where high temperature strength is required. The high chromium content which is so beneficial to the wet corrosion resistance of stainless steels is also highly beneficial to their high temperature strength and resistance to scaling at elevated temperatures
FAQ
Q: What's your advantage?
A: We have a large number of professional technical personnel, more competitive prices than other steel companies and the best after-sales service.
Q: Do you offer after-sales services?
A: Certainly. If you have any questions, please feel free to contact us. We will do our best to solve the problems and satisfy you.
Q: How about the delivery time?
A: Within 4-35 days after we confirm your orders. Depending on different products.
Q: How do you control quality?
A: All products are produced in strict accordance with relevant product standards, and the products are tested by relevant instruments and experimental equipment during the production process.
Q: Does the product have quality inspection before loading?
A: Of course, all our products have undergone strict quality inspection before packing. We accept customer’s inspection before loading.
